ProRes Video Recorder

Rack mount recorder designed for Outdoor Broadcast Van

UHD 4K Recording and Compressed in 10-Bit 4:2:2 ProRes

Large 5'' LCD Touch screen for operating and monitoring

ISO Recording of four videos, , 3G ISO recording and HD playback

Supports multiple inputs and output configurations

2 x XLR Analogue Audio Inputs and 2 x XLR Analogue Audio Outputs

Easy post-edit and playback

Vector Scope

A recorder that can be operated like a video switcher

Closed Caption

Спецификация

HDR-90 4K ProRes Video Recorder-1U Rackmountable
Video Standard	UHD & HD
Video Format	2160p 23.98/24/25/29.97/30/50/59.94/60Hz 1080p 23.98/24/25/29.97/30/50/59.94/60Hz 1080i 50/59.94/60Hz 720p 50/59.94/60Hz
Supported Video Input Signal	1x 3G/12G-SDI 3x 3G-SDI 1x HDMI 2.0 1x HDMI 1.4
Video Output	1x 3G/12G-SDI 1x HDMI 2.0 3x HDMI 1.4
Analog Audio Input	2x Balanced XLR
Analog Audio Output	2x Balanced XLR
Embedded Audio	SDI Input / Output (8CH ) HDMI Input / Output (8CH)
Storage Medium	2.5" SSD
Multi-channel Recording	Yes, 4-CH HD
Estimated Record Time (min per 10GB)	HD: 27 (Proxy), 11.5 (LT), 8 (Standard), 5.5 (HQ) 3G: 13 (Proxy), 6 (LT), 4 (Standard), 2.5 (HQ)
Recording Media	2x 2.5" Removable SSD
Storage File System	exFAT
Recorded File Format	QuickTime .MOV
Video Recording Bit Rate / Color Sampling	ProRes 422 HQ ProRes 422 ProRes 422 LT ProRes 422 Proxy
Audio Recording Format	Uncompressed PCM Sampling rate 48KHz 24bit
Preview Display	5" Touch LCD
Time Code In / Out	Yes
External Sync / Genlock	Black Burst & Tri-level with loop thru
External Control	RS-232/422 (Dsub 9pin), DVIP (Ethernet), GPI (3.5Ø phone jack)
Chassis	1RU rack-mountable
Dimension (LxWxH)	440 x 300 x 49 mm
Weight	4 kg
Operating Temp. Range	0~40 °C
Power	DC 12V
What's in the Box	1x HDR-90 Unit 1x Adapter + AC Cord 1x Thank You Card 2x 2.5” Removable HDD/SSD Enclosure 8x Screws for 2.5 Removable HDD/SSD Enclosure 2x Blank Label 1x SATA to USB Cable
Approved SSD Drives	Samsung Pro 860
