SC6D0N1 HDMI2.0+

1CH HDMI2.0 4KP60 ENCODER+DECODER

Slogan	1CH HDMI2.0 4KP60 ENCODER+DECODER
Model Name	SC6D0N1 HDMI2.0+
Max. FPS	3840×2160p@60/50fps
Recording Mode	Hardware Compression
5G Support	N/A

A/V Input Interfaces	Video 1×HDMI2.0 Audio 1×3.5mm stereo analog audio
A/V Output Interface	Video 1×HDMI2.0 Audio 1×3.5mm stereo analog audio
Video Feature	H.265(HEVC)/H.264/AVC, Baseline/Main/High Profile Configurable Bit Rate Up to 64Mbps Support input / output resolutions 3840×2160p@60/50fps 3840×2160p@30/25/24fps 1920×1080p@60/50fps 1920×1080p@30/25/24fps 1280×720p@60/50fps 1280×1024p@60fps 1280×960p@60fps 1024×768p@60fps 800×600p@60fps 640×480p@60fps 720×480p@60fps 720×576p@50fps
Audio Feature	AAC-LC Configurable bit rate range from 32Kbps to 384Kbps Sample rate : 48KHz, 16bit, Stereo

Network Feature	1×RJ45 for 10/100/1000Mbps Ethernet DHCP client
Support Streaming protocol	NDI Support ( Separate License with NDI Required ) RTSP over UDP/TCP/Multicast/HTTP RTMP public (web portal) TS over IP HLS ** optional by customer request

Misc. Features

Web UI for system configuration
Firmware upgradable
LED indicator
Status with Power Recycle
1×USB3.0 (For external storage usage)
2×USB2.0 (For Keyboard and mouse usage)
1×RS232 + 1×RS485

Record Format

MP4 / TS / MOV

Power Supply

DC input : 12V / 2A
Support POE input
